1R1G1B SMD2121 Led Stage Screen Rental High Refresh Rate 3.91mm Pixel pitch
Product Description:
1. With the best quality IC MBI5153, refresh rate can be reached 3840HZ, and show you the perfect visual effect.
2. Die-casting aluminum technology, together white the hight-percision CNC procession, makes the precision reach±0.05mm so as to achieve seamless assembly.
3. The Die casting aluminum cabinet makes the single cabinet as light as 8KG.
4. Specially designed masks can make the horizontal viewing angle up to 140 degrees.
5. The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.
6. No need to disassemble the whole screen for maintenance. Each components can be detached individually for that purpose.
Technical Specifications:
| Small Pixel Outdoor LED Display |
| Module | Pixel Pitch | 3.91mm |
| | Module size | 250mmx500mm |
| | Density of pixel/(dots/m2) | 65536 |
| | Led encapsulation | SMD2121 |
| | Resolution of module | 64X128 dots |
| Main | Optimum viewing distance | 4m |
| | View angle / ° | 140 H,120 V |
| | Max power consumption/W/M2 | 900 |
| | Size of cabinet/mm | 500X1000 |
| | Resolution of cabinet | 128x256 |
| | Weight of cabinet/kg | 13 |
| | Driving method | 1/16 scan constant current |
| | Refresh rate Hz/S | ≥3840 |
| | Luminance of white balance | ≥1200 nits |
| | Waterproof rate | IP43(front)/ IP43(back) |
| | Working vlotage | 110-220 VAC/+/- 10% |
| | Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
| | Control system | Novastar(sending card,receiving cards and Hubs) |
| | Average of non-failure life | >50,00h |
| | Life span | >100,000h |
| | Functionaless dot rate | <0.01% |
Detail Product Pictures:
FAQ:
Q1: Where is Rental LED display screen used for?
A2: For Indoor & Outdoor useage. Widely used for rental / hire business, backdrop of staging event, liveshow, concert, etc.
Q2: What's the pixel pitch for rental type LED Display Screen ?
A1: At Indoor&Outdoor P2.5mm/P2.9mm/P3mm/P3.75mm/4mm/4.81mm/5mm/5.95mm/P6mm)
Q3: Can it play HD video?
A3: Sure, it can realize HD video function with Novastar And Linsn controlling system.
Q4: How about the size of project?
A4: We need the size with "width by height" of your project, and then we wil provide you suitable solution. We will very appreciate it if you could send any drawing files or photograph of installation place.
Q5: What's the controlling system?
A5: The standard controlling system is Novastar. Also support Linsn too.
